• Paint, solid
• Bumper, front, chrome, with Gray lower
• Bumper, rear, chrome step, includes pad (Not available with (ZW9) Pickup bed, delete)
• Air dam, Gray
• Moldings, bodyside (Moldings are color-keyed and not available with (ZW9) Pickup bed delete. - Refer to Color and Trim Chart for compatibility)
• Wheel flares (Refer to Color and Trim chart for compatibility. Front only when (ZW9) Pickup bed delete is ordered)
• Grille, color-keyed surround, with chrome accent bar
• Headlamps, dual halogen composite, includes flash-to-pass feature and automatic lamp control
• Daytime running lamps, includes automatic exterior lamp control
• Lamps, dual cargo area lamps
• Mirrors, outside rearview, manual folding, power, heated, Black (Upgradeable to (DL3) Mirrors, outside rearview, power folding, power, heated or (DPF) Mirrors, outside rearview, power, heated, camper-style.)
• Glass, Solar-Ray light tinted, all windows
• Windows, rear quarter swing-out (Standard with Extended Cab Models only.)
• Wipers, intermittent, front, wet-arm with pulse washers

• Seat trim, Custom Cloth
• Seats, front 40/20/40 split-bench, 3-passenger, driver and passenger manual reclining, center fold-down armrest with storage, adjustable outboard head restraints and storage pockets on Extended Cab Models (Not available with (UC6) Sound system, ETR AM/FM stereo with 6-disc CD changer.)
• Seats, rear bench, folding, 3-passenger (includes child seat top tether anchor) (Not available with Regular Cab Models.)
• Floor covering, color-keyed carpeting and rubberized vinyl floormats (May be substituted with (BG9) Floor covering, rubberized vinyl)
• Steering wheel, leather-wrapped rim, Black, includes theft-deterrent locking feature
• Theft-deterrent system, PASSlock II
• Driver Information Center, monitors numerous systems depending on vehicle equipment
• Warning tones, headlamp on, key-in-ignition, driver and passenger buckle-up reminder, turn signal on
• Defogger, rear-window, electric (Not available with (A28) Window, rear sliding)
• Cruise control, electronic with set and resume speed, includes telltale in instrument panel cluster
• Door locks, power
• Windows, power, includes driver and passenger express-down
• Keyless entry, remote, includes 2 transmitters, panic button and content theft alarm
• Air conditioning, dual-zone, manual, individual climate settings for driver and right front passenger
• Sound system, ETR AM/FM stereo with CD player, includes seek-and-scan, digital clock, auto-tone control, speed-compensated volume, and Radio Data System (RDS) (Requires (AE7) Seats, front 40/20/40 split-bench. Upgradeable to (UB1) Sound system, ETR AM/FM stereo with CD and cassette player or (UC6) Sound system, ETR AM/FM stereo with 6-disc CD changer on Extended and Crew Cab Models. - Includes 4 speakers on Regular Cab and 6 speakers on Extended and Crew Cab Models.)
• Cupholders, front (Also includes rear cupholders on Extended and Crew Cab Models.)
• Cigarette lighter, on instrument panel
• Power outlets, auxiliary, covered, 2 dash-mounted, 12-volt
• Mirror, inside rearview, electrochromic (light-sensitive auto dimming), 8-point compass and outside temperature indicator
• Visors, padded, Shale-colored, driver and passenger side with cloth trim, extenders, pocket on driver side and vanity mirror on passenger side
• Console, overhead mini, includes map lights
• Assist handle, front passenger (Also includes rear outboard passenger assist on Extended and Crew Cab Models.)
• Lighting, dome lamp, reading, backlit instrument panel switches and door handle-activated illuminated entry
• Coat hook, driver side (Also includes passenger side coat hook on Extended and Crew Cab Models.)

• Brakes, 4-wheel antilock, 4-wheel disc
• Air bags, frontal, driver and right front passenger (Regular and Extended Cab Models includes passenger side deactivation switch. - Always use safety belts and proper child restraints, even with air bags. Children are safer when properly secured in a rear seat. See the Owner's Manual for more safety information)
• Daytime running lamps, includes automatic exterior lamp control

ENGINE, VORTEC 6000 V8 SFI

(300 HP @ 4400 rpm 360 lb.-ft. @ 4000 rpm) (STD)

TRANSFER CASE, ELECTRONIC SHIFT

includes push-button controls

CONSOLE, FLOOR

includes storage compartment and dual cupholders

TIRES, LT245/75R16E, ALL-SEASON, BLACKWALL

(STD) (Includes 5 tires with (E63) Pickup bed Fleetside box. -Includes 4 tires with (ZW9) Pickup bed delete)

SKID PLATE PACKAGE

includes aluminum front underbody shield starting behind front bumper and running to 1st cross-member protecting front underbody oil pan differential case and transfer case frame-mounted shields -Included with (VYU) Snow Plow Prep Package.)

SEAT TRIM, CUSTOM CLOTH

(STD)

AIR CLEANER, HIGH-CAPACITY

(Included with (LLY) Engine Duramax 6600 Turbo Diesel V8. -Included with (Z82) Trailering equipment heavy-duty. -Included with (VYU) Snow plow prep package)

GLASS, SOLAR-RAY DEEP TINTED

(all windows except light tinted glass on windshield)

SOUND SYSTEM FEATURE, XM SATELLITE RADIO

features 67 channels of 100% commercial-free music included in its over 150 channels of the best in music news sports talk comedy XM Instant Traffic and Weather and more. Digital quality sound with coast-to-coast signal coverage. Three trial months-no obligation

TRANSMISSION, 4-SPEED AUTOMATIC, HEAVY-DUTY, ELECTRONICALLY CONTROLLED WITH OVERDRIVE, TOW/HAUL MODE

and (KNP) Cooling external transmission oil cooler

SOUND SYSTEM, ETR AM/FM STEREO WITH CD AND CASSETTE PLAYER

includes seek-and-scan digital clock auto-tone control speed-compensated volume TheftLock Radio Data System (RDS) and 4-speakers on Regular Cab Models 6 speakers on Extended and Crew Cab Models (with bucket seats UB1 includes Bose speaker system Bose amplifier and Bose subwoofer)

ENGINE BLOCK HEATER

(Included with (LLY) Engine Duramax 6600 Turbo Diesel V8)

SEATS, FRONT RECLINING BUCKETS, DUAL ADJUSTABLE HEAD RESTRAINTS

(AG1) Seat adjuster power driver 6-way passenger manual recline inboard armrests and storage pockets

PREFERRED EQUIPMENT GROUP

Includes Standard Equipment

SEAT ADJUSTER, POWER DRIVER 6-WAY

(Included with (A95) Seats front reclining buckets. -Included with (**2) Seat trim leather on Extended and Crew Cab Models)

WHEELS, 4-16" X 6.5" (40.6 CM X 16.5 CM) 8-LUG CHROME-STYLED STEEL

includes chrome center caps and steel spare (STD)

PAINT, SOLID

(STD)

TRAILERING EQUIPMENT, HEAVY-DUTY

includes trailering hitch platform 7-wire harness (harness includes wires for: park lamps backup lamps right turn left turn electric brake lead battery and ground) with independent fused trailering circuits mated to a 7-way sealed connector 7-way to 4-way trailer adapter instrument panel jumper wiring harness for electric trailer brake controller and 1-way sealed connector for center high-mounted stop/brake lamp. Also includes (K47) Air cleaner high capacity

GVWR, 9200 LBS. (4173 kg)

(STD)

• ENGINE VORTEC 6000 V8 SFI (300 HP @ 4400 rpm 360 lb.-ft. @ 4000 rpm) (STD)
• TRANSFER CASE ELECTRONIC SHIFT includes push-button controls
• CONSOLE FLOOR includes storage compartment and dual cupholders
• REAR AXLE 4.10 RATIO
• TIRES LT245/75R16E ALL-SEASON BLACKWALL (STD) (Includes 5 tires with (E63) Pickup bed Fleetside box. -Includes 4 tires with (ZW9) Pickup bed delete)
• SKID PLATE PACKAGE includes aluminum front underbody shield starting behind front bumper and running to 1st cross-member protecting front underbody oil pan differential case and transfer case frame-mounted shields -Included with (VYU) Snow Plow Prep Package.)
• SEAT TRIM CUSTOM CLOTH (STD)
• AIR CLEANER HIGH-CAPACITY (Included with (LLY) Engine Duramax 6600 Turbo Diesel V8. -Included with (Z82) Trailering equipment heavy-duty. -Included with (VYU) Snow plow prep package)
• GLASS SOLAR-RAY DEEP TINTED (all windows except light tinted glass on windshield)
• REGULAR PRODUCTION ACCESSORY UNDERSEAT STORAGE REAR LOCKABLE
• SOUND SYSTEM FEATURE XM SATELLITE RADIO features 67 channels of 100% commercial-free music included in its over 150 channels of the best in music news sports talk comedy XM Instant Traffic and Weather and more. Digital quality sound with coast-to-coast signal coverage. Three trial months-no obligation
• MIRRORS OUTSIDE REARVIEW POWER FOLDING POWER HEATED STAINLESS STEEL DRIVER SIDE ELECTROCHROMIC (LIGHT-SENSITIVE AUTO-DIMMING) TURN SIGNAL IN GLASS AND CURB-TILT
• TRANSMISSION 4-SPEED AUTOMATIC HEAVY-DUTY ELECTRONICALLY CONTROLLED WITH OVERDRIVE TOW/HAUL MODE and (KNP) Cooling external transmission oil cooler
• COOLING EXTERNAL TRANSMISSION OIL COOLER AUXILIARY HEAVY-DUTY AIR-TO-OIL
• SOUND SYSTEM ETR AM/FM STEREO WITH CD AND CASSETTE PLAYER includes seek-and-scan digital clock auto-tone control speed-compensated volume TheftLock Radio Data System (RDS) and 4-speakers on Regular Cab Models 6 speakers on Extended and Crew Cab Models (with bucket seats UB1 includes Bose speaker system Bose amplifier and Bose subwoofer)
• ENGINE BLOCK HEATER (Included with (LLY) Engine Duramax 6600 Turbo Diesel V8)
• SEATS FRONT RECLINING BUCKETS DUAL ADJUSTABLE HEAD RESTRAINTS (AG1) Seat adjuster power driver 6-way passenger manual recline inboard armrests and storage pockets
• PREFERRED EQUIPMENT GROUP Includes Standard Equipment
• SEAT ADJUSTER POWER DRIVER 6-WAY (Included with (A95) Seats front reclining buckets. -Included with (**2) Seat trim leather on Extended and Crew Cab Models)
• SOUND SYSTEM FEATURE STEERING WHEEL MOUNTED RADIO CONTROLS RADIO AND DRIVER INFORMATION CENTER (DIC)
• WHEELS 4-16 X 6.5 (40.6 CM X 16.5 CM) 8-LUG CHROME-STYLED STEEL includes chrome center caps and steel spare (STD)
• DIFFERENTIAL LOCKING HEAVY-DUTY REAR
• PAINT SOLID (STD)
• TRAILERING EQUIPMENT HEAVY-DUTY includes trailering hitch platform 7-wire harness (harness includes wires for: park lamps backup lamps right turn left turn electric brake lead battery and ground) with independent fused trailering circuits mated to a 7-way sealed connector 7-way to 4-way trailer adapter instrument panel jumper wiring harness for electric trailer brake controller and 1-way sealed connector for center high-mounted stop/brake lamp. Also includes (K47) Air cleaner high capacity
• GVWR 9200 LBS. (4173 kg) (STD)
• Daytime running lamps includes automatic exterior lamp control
• Air bags frontal driver and right front passenger (Regular and Extended Cab Models includes passenger side deactivation switch. - Always use safety belts and proper child restraints even with air bags. Children are safer when properly secured in a rear seat. See the Owner's Manual for more safety information)
• Brakes 4-wheel antilock 4-wheel disc
• Driver Information Center monitors numerous systems depending on vehicle equipment
• Lighting dome lamp reading backlit instrument panel switches and door handle-activated illuminated entry
• Cigarette lighter on instrument panel
• Seats front 40/20/40 split-bench 3-passenger driver and passenger manual reclining center fold-down armrest with storage adjustable outboard head restraints and storage pockets on Extended Cab Models (Not available with (UC6) Sound system ETR AM/FM stereo with 6-disc CD changer.)
• Keyless entry remote includes 2 transmitters panic button and content theft alarm
• Air conditioning dual-zone manual individual climate settings for driver and right front passenger
• Sound system ETR AM/FM stereo with CD player includes seek-and-scan digital clock auto-tone control speed-compensated volume and Radio Data System (RDS) (Requires (AE7) Seats front 40/20/40 split-bench. Upgradeable to (UB1) Sound system ETR AM/FM stereo with CD and cassette player or (UC6) Sound system ETR AM/FM stereo with 6-disc CD changer on Extended and Crew Cab Models. - Includes 4 speakers on Regular Cab and 6 speakers on Extended and Crew Cab Models.)
• Cupholders front (Also includes rear cupholders on Extended and Crew Cab Models.)
• Console overhead mini includes map lights
• Warning tones headlamp on key-in-ignition driver and passenger buckle-up reminder turn signal on
• Defogger rear-window electric (Not available with (A28) Window rear sliding)
• Theft-deterrent system PASSlock II
• Mirror inside rearview electrochromic (light-sensitive auto dimming) 8-point compass and outside temperature indicator
• Windows power includes driver and passenger express-down
• Steering wheel leather-wrapped rim Black includes theft-deterrent locking feature
• Cruise control electronic with set and resume speed includes telltale in instrument panel cluster
• Door locks power
• Assist handle front passenger (Also includes rear outboard passenger assist on Extended and Crew Cab Models.)
• Steering column Tilt-Wheel adjustable includes brake/transmission shift interlock
• Seats rear bench folding 3-passenger (includes child seat top tether anchor) (Not available with Regular Cab Models.)
• Floor covering color-keyed carpeting and rubberized vinyl floormats (May be substituted with (BG9) Floor covering rubberized vinyl)
• Visors padded Shale-colored driver and passenger side with cloth trim extenders pocket on driver side and vanity mirror on passenger side
• Seat trim Custom Cloth
• Coat hook driver side (Also includes passenger side coat hook on Extended and Crew Cab Models.)
• Power outlets auxiliary covered 2 dash-mounted 12-volt
• Instrumentation analog includes speedometer odometer with trip odometer fuel level voltmeter engine temperature oil pressure and tachometer
• Headlamps dual halogen composite includes flash-to-pass feature and automatic lamp control
• Air dam Gray
• Daytime running lamps includes automatic exterior lamp control
• Wheel flares (Refer to Color and Trim chart for compatibility. Front only when (ZW9) Pickup bed delete is ordered)
• Glass Solar-Ray light tinted all windows
• Grille color-keyed surround with chrome accent bar
• Moldings bodyside (Moldings are color-keyed and not available with (ZW9) Pickup bed delete. - Refer to Color and Trim Chart for compatibility)
• Bumper rear chrome step includes pad (Not available with (ZW9) Pickup bed delete)
• Mirrors outside rearview manual folding power heated Black (Upgradeable to (DL3) Mirrors outside rearview power folding power heated or (DPF) Mirrors outside rearview power heated camper-style.)
• Wipers intermittent front wet-arm with pulse washers
• Lamps dual cargo area lamps
• Paint solid
• Bumper front chrome with Gray lower
• Windows rear quarter swing-out (Standard with Extended Cab Models only.)
• Four Wheel Drive
• Tow Hooks
• Tires - Front All-Season
• Tires - Rear All-Season
• Conventional Spare Tire
• Chrome Wheels
• Power Steering
• ABS
• 4-Wheel Disc Brakes
• Automatic Headlights
• Daytime Running Lights
• Automatic Headlights
• Heated Mirrors
• Power Mirror(s)
• Intermittent Wipers
• Cloth Seats
• Split Bench Seat
• Rear Bench Seat
• Floor Mats
• Adjustable Steering Wheel
• Leather Steering Wheel
• Immobilizer
• Rear Defrost
• Cruise Control
• Power Door Locks
• Power Windows
• Security System
• Keyless Entry
• Power Door Locks
• Multi-Zone A/C
• A/C
• AM/FM Stereo
• CD Player
• Power Outlet
• Auto-Dimming Rearview Mirror
• Passenger Vanity Mirror
• Front Reading Lamps
• Front Reading Lamps
• ABS
• 4-Wheel Disc Brakes
• Driver Air Bag
• Passenger Air Bag
• Passenger Air Bag On/Off Switch
• Daytime Running Lights
• Automatic Headlights

• Electrical
• Cold Cranking Amps @ 0° F (Primary): 600
• Maximum Alternator Capacity (amps): 105
• Cooling System
• Total Cooling System Capacity (qts): 16.0
• Total Cooling System Capacity (qts): 16.4
• Weight Information
• Gross Axle Wt Rating - Front (lbs): 4670
• Gross Axle Wt Rating - Rear (lbs): 6084
• Curb Weight - Front (lbs): 3295
• Curb Weight - Rear (lbs): 2242
• Gross Vehicle Weight Rating Cap (lbs): 9200
• Gross Combined Wt Rating (lbs): 16000
• Trailering
• Dead Weight Hitch - Max Trailer Wt. (lbs): 5000
• Dead Weight Hitch - Max Tongue Wt. (lbs): 500
• Wt Distributing Hitch - Max Trailer Wt. (lbs): 10000
• Wt Distributing Hitch - Max Tongue Wt. (lbs): 1500
• Fifth Wheel Hitch - Max Trailer Wt. (lbs): 10100
• Fifth Wheel Hitch - Max Tongue Wt. (lbs): 2525
• Suspension
• Suspension Type - Front: Torsion Bar
• Suspension Type - Rear: 2-Stage Multi-Leaf
• Spring Capacity - Front (lbs): 4800
• Spring Capacity - Rear (lbs): 6084
• Axle Type - Rear: Full-Floating
• Axle Capacity - Front (lbs): 4800
• Axle Capacity - Rear (lbs): 6900
• Axle Ratio (:1) - Front: 4.10
• Axle Ratio (:1) - Front: 3.73
• Axle Ratio (:1) - Rear: 4.10
• Shock Absorber Diameter - Front (mm): 36
• Shock Absorber Diameter - Rear (mm): 36
• Stabilizer Bar Diameter - Front (in): 1.42
• Brakes
• Brake Type: Pwr
• Brake ABS System: Four-Wheel
• Disc - Front (Yes or ): Yes
• Disc - Rear (Yes or ): Yes
• Front Brake Rotor Diam x Thickness (in): 12.8 x 1.5
• Rear Brake Rotor Diam x Thickness (in): 13 x 1.1
• Tires
• Front Tire Order Code: QIZ
• Rear Tire Order Code: QIZ
• Spare Tire Order Code: QIZ
• Front Tire Size: LT245/75R16
• Rear Tire Size: LT245/75R16
• Spare Tire Size: LT245/75R16
• Front Tire Capacity (lbs): 2335
• Rear Tire Capacity (lbs): 3042
• Spare Tire Capacity (lbs): 2335
• Revolutions/Mile @ 45 mph - Front: - TBD -
• Revolutions/Mile @ 45 mph - Rear: - TBD -
• Revolutions/Mile @ 45 mph - Spare: - TBD -
• Wheels
• Front Wheel Size (in): 16 x 6.5
• Rear Wheel Size (in): 16 x 6.5
• Spare Wheel Size (in): 16 x 6.5
• Front Wheel Material: Steel
• Rear Wheel Material: Steel
• Spare Wheel Material: Steel
• Steering
• Steering Type: Pwr
• Steering Ratio (:1), On Center: 24.0
• Steering Ratio (:1), At Lock: - TBD -
• Turning Diameter - Curb to Curb (ft): 46.8
• Turning Diameter - Wall to Wall (ft): - TBD -
• Frame
• Frame Type: Ladder
• Fuel Tank
• Fuel Tank Capacity, Approx (gal): 26
• Fuel Tank Location: LH
• Exterior Dimensions
• Wheelbase (in): 143.5
• Length, Overall w/o rear bumper (in): 227.7
• Width, Max w/o mirrors (in): 79.7
• Height, Overall (in): 76.2
• Overhang, Front (in): 37.0
• Overhang, Rear w/o bumper (in): 47.2
• Front Bumper to Back of Cab (in): 138.6
• Cab to Axle (in): 41.9
• Cab to End of Frame (in): - TBD -
• Ground to Top of Load Floor (in): - TBD -
• Ground to Top of Frame (in): - TBD -
• Frame Width, Rear (in): - TBD -
• Ground Clearance, Front (in): 10.6
• Ground Clearance, Rear (in): 13.6
• Cargo Area Dimensions
• Cargo Box Length @ Floor (in): 78.7
• Cargo Box Width @ Top, Rear (in): 61.9
• Cargo Box Width @ Floor (in): 64.8
• Cargo Box Width @ Wheelhousings (in): 50.0
• Cargo Box (Area) Height (in): 19.5
• Tailgate Width (in): 61.9
• Cargo Volume (ft³): 59.0
• Ext'd Cab Cargo Volume (ft³): - TBD -
• Interior Dimensions
• Passenger Capacity: 5
• Passenger Capacity: 6
• Front Head Room (in): 41.0
• Front Leg Room (in): 41.3
• Front Shoulder Room (in): 65.2
• Front Hip Room (in): 61.4
• Second Head Room (in): 38.4
• Second Leg Room (in): 33.7
• Second Shoulder Room (in): 66.3
• Second Hip Room (in): 61.5
• Summary
• Vehicle Name: Chevrolet Silverado 2500HD
• Body Style: Ext Cab 6.5' Fleetside
• Body Code: E63
